Product image is representative; revision or series may vary. Contact us to request a specific version.
Eaton
Eaton 109971 NZMS2-M40
The Eaton 109971 is a Motor protection molded case circuit breaker, part of the Eaton Drives – Motors – Circuits Protection range. It offers a 400/415 V supply, 40 A rated current, 3 poles and IP20 protection.
Prices include 5% VAT.
1-Year Warranty
Automation parts backed by our complimentary 1-year warranty.
Fast Shipping
Fast domestic and international shipping worldwide.
Payment Flexibility
Major cards, wire transfer, PO and net terms for businesses.
Repairs & Exchanges
In-house repairs and exchanges across all automation products.
Reseller Options
Drop-shipping, blind shipping and account shipping available.
Not an authorized distributor: CMP Automate is not an authorized distributor for the manufacturers or trademarks listed, and the manufacturer's warranty does not apply. All products come with CMP Automate's 1-year warranty.
Technical specifications for 109971 NZMS2-M40
| Supply voltage | 400/415 V |
|---|---|
| Rated current | 40 A |
| Degree of protection | IP20 |
| Number of poles | 3 |
Description
Motor protection molded case circuit breaker, NZMS2 M40. 3 pole, rated uninterrupted current 40 A overload release setting range 32 40 A non delayed short circuit setting 320 560 A thermomagnetic trip, trip class 10 phase failure sensitive rated operational voltage up to 690 V rated breaking capacity 150 kA Icu/Ics at 400/415 V screw main terminals rocker lever actuator protection degree IP20 dimensions H184 W105 D149 mm.
Technical notes
Specifications and images are representative and may vary by revision or series. Confirm firmware and revision requirements with our specialists before ordering.
